the project
Help facilitate increased use of already existing open space
the steps
We need funding to cover materials cost. Once in place the structure will be built by GrowNYC staff and with 15 teen interns from our summer program. A landscape architect has already completed a blue print and material costsfor the structure. GrowNYC staff has necessary carpentry skills and ability to work with teenagers on construction projects.
why we're doing it
The JDD community garden in the South Bronx needs a new shade structure -- the exisitng one is in need of repair. Building a new structure will allow the Learn It, Grow It, Eat It program of GrowNYC to increase its use of the garden as an outdoor classroom for neighboring schools. The community will use the structure to hold more neighborhood events that will bring more people into the garden
budget
Roof- 7 12' 2x6 joists -$96, 7 14' 2x6 joists - $77, 14 2x10 joist hangers - $182, 8 12' 36""x12' metal sheets - $320, 2 boxes of 200 self tapping screws - $40, 10 12' 2x6beams - $80 6 16' gutters - $102, 4 gutter connectors - $12, 3 gutter corners - $18, 3-10 pack gutter screws $30, 1 gutter drop outlet - $6 Total roof cost $963
Deck - 85 12' 2x4 decking - $425, 18 12' 2x10 joists, $252, 12 2x10 joist hangers - $156, 10 12' 2x8 beams - $120, 8 10' 4x4 footers - $80, 6 14' 2x6 face boards - $66, 30 80lg bags cement for 15 posts - $150 Total deck cost - $1,249
Body - 10 10' 4x4 posts - $110, 1 12' 4x4 post - $13, 4 10' 2x6 angle supports - $28, 14 14' 2x6 face boards $154, 4 plywood mural boards - $40, 20' link chain - $20, 8 14' 2x6 railings Total body cost - $453
Benches - 10 12' 2x6 seats - $80, 1 12' 2x10 supports - $14, 10 12' 2x4 facings - $50 Total bench cost $144
Misc 25lbs 3"" exterior screws - $100, 40 3"" 3/8x3"" lag bolts -$20 Total Misc - $120
Total Deck Cost Estimate - $2,929
costs from Home Depot
